Wi-Fi 6 Outdoor Access Point | ion4x

Dual Band 2x2:2 Outdoor Access Point with Integrated Antenna (8 dBi)

Wi-Fi 6 Outdoor Access Point -Tough on
Weather, Fast on Performance

The ion4x Wi-Fi 6 outdoor access point delivers robust, high-speed connectivity across challenging environments with its dual-band 2x2:2 and integrated antennas. Perfectly suited for outdoor stadiums, car parks, garden and pool areas, and transit stations, this outdoor access point powers seamless fan engagement in sports arenas, supports automated ticketing and security in healthcare car parks, enhances guest experiences in hospitality zones, and ensures commuters stay connected with real-time updates at train stations.

Built to withstand outdoor conditions, this outdoor wireless access point guarantees uninterrupted performance in the busiest public hotspots.

Radio Capabilities

  • 802.11ax (with Backward Compatibility)

  • Dual-radio (2.4GHz, 5GHz)

  • 2x2:2 MIMO per Radio

  • 1.78 Gbps Peak Data Rate

  • Up to 30dBm Tx Power per Radio

  • Integrated, Directional Antenna (70º ± 5ºH & 70º ± 5ºV Beamwidth) with 8 dBi Gain on Each Radio

Interfaces

  • 1x1GbE (PoE)

  • 1x2.5GbE SFP

Wireless

  • Auto Channel and Power Management

  • Fast Roaming (802.11r)

  • Passpoint 2.0

  • Advanced Radio Resource Management

  • Wi-Fi Certified EasyMesh®

  • Client Emulation

Networking

  • IPv4/IPv6

  • L2 Tunneling (EoGRE)

  • Link Aggregation

Security

  • WPA3, OWE, PMF

  • WIDS and WIPS

  • Content Filtering

  • L2-L4 ACL

  • Dedicated Sensor Mode

  • Client Isolation

Management

  • On-prem/cloud controller

  • TIP OpenWiFi controller

Applications

Education

Sports Arena

Lag-free connectivity for streaming, real-time analytics, smart scoreboard integration, and enhanced fan engagement.

Healthcare

Car Parks

Reliable network access for automated ticketing, security, and navigation.

Hospitality

Garden & Pool Areas

Outdoor Wi-Fi for relaxation, capturing moments, and staying connected with loved ones.

Mass Transit

Train Station

High-speed access for commuters, ticketing, and real-time transit information.

Variants

ion4x_2

IO Wi-Fi 6 Dual Band 2x2:2 Outdoor Access Point with 60⁰H/ 15⁰V beamwidth and 14 dBi gain

ion4x_3

IO Wi-Fi 6 Dual Band 2x2:2 Outdoor Access Point with 45⁰H/ 27⁰V beamwidth and 13 dBi gain

ion4x_ext

IO Wi-Fi 6 Dual Band 2x2:2 Outdoor Access Point with 70⁰H/ 70⁰V beamwidth and 8 dBi gain [ Extended Temperature]

ion4x2_ext

IO Wi-Fi 6 Dual Band 2x2:2 Outdoor Access Point with 60⁰H/ 15⁰V beamwidth and 14 dBi gain [ Extended Temperature]

ion4x3_ext

IO Wi-Fi 6 Dual Band 2x2:2 Outdoor Access Point with 45⁰H/ 27⁰V beamwidth and 13 dBi gain [ Extended Temperature]

Insights

Case Study

Powering Large-Scale Events with High-Performance Wi-Fi

Delivering Uninterrupted Connectivity to Keep Every Guest, Device, and Experience Connected…

Case Study

Mobile Data Offloading Boosts Telecom Network Efficiency

HFCL’s Wi-Fi Access Solutions Enhance Capacity and Elevate User Experience...

Video

Enhancing Wi-Fi Performance in MDUs with IO by HFCL Wi-Fi 6 Indoor AP

Looking to Boost Wi-Fi Performance in Multi-Dwelling Units (MDUs)? Discover How...

Frequently Asked Questions

Find answers to key questions about our Wi-Fi Access Points to
help you choose the right solution for your network

What is the weather resistance rating of ion4x Wi-Fi 6 Outdoor Access Point?

This outdoor Access Point is designed to withstand harsh environments with an IP67 rating. This means it is completely protected from dust ingress and can withstand temporary immersion in water up to 1 meter deep for 30 minutes. It also has features like 6KV lightning protection and 15KV ESD protection to ensure reliability during storms.

Can ion4x outdoor Access Point be powered by Power over Ethernet (PoE)?

Yes, this outdoor Access Point supports both 802.3at PoE+ and Passive PoE. This simplifies installation by allowing both data and power to be delivered over a single Ethernet cable, which is essential for outdoor deployments where power outlets may not be readily available.

How does Wi-Fi 6 outdoor Access Points handle a large number of connected devices?

The Wi-Fi 6 technology, specifically OFDMA and MU-MIMO, allows the outdoor Access Point to communicate with multiple devices at once. This significantly improves network efficiency and performance in high-density environments like outdoor cafes, stadiums, public parks or expansive spaces.

What are the best practices for placing an outdoor Access Point?

Proper placement is crucial. You should mount the Access Point with a clear line of sight to the desired coverage area, away from major obstructions like thick walls, dense foliage, or large metal structures. It's often recommended to mount the AP on a pole or wall at a height of 4-6 meters to maximize coverage and minimize interference.

Should I choose an Access Point with an omnidirectional or directional antenna?

The choice depends on your coverage needs. An omnidirectional antenna broadcasts the signal in all directions and is best for providing general, 360-degree coverage from a central location. A directional antenna focuses the signal in a specific direction and is ideal for covering a longer, more narrow area, such as a long driveway or a specific part of a yard, or for creating a point-to-point wireless bridge.
