RJ45 Ports: 10/ 100/ 1000 BaseT(X) for PoE OUT and DATA IN
PoE Pinout Default: 1,2,4,5 V+ , V- for pin 3,6,7,8 (4 pairs)
Interface
Input Voltage: 100-264 V AC for AC Model & 36-75 VDC for DC Model
Power Budget: Max. 20 W for 1 PDs consumption
Power Requirement
Dimensions: DC-PoE: 145 x 82 x 45 mm and AC-PoE: 136 x 82 x 45 mm
Weight: DC-PoE: 0.32 kg & AC-PoE: 0.38 kg
Physical Characteristics
Operating Temperature: 0°C to 45°C
Storage Temperature: -40°C to 85°C
Ambient Relative Humidity: 5% to 95% (non-condensing)
Environmental Limits
ion4xi, ion4xi_WP, ion4x_3, ion4x_2, ion4x, ion4xe
Applicability
