1 Gbps Point-to-Point Small Form Factor UBR | ion4xls

5.1 to 5.9 GHz 1 Gbps Compact UBR with Integrated Flat Panel Antenna

Compact, Smart, High-Speed Connectivity for Modern Networks

The ion4xls is a high-performance Point-to-Point Unlicensed Band Radio designed for carrier-grade wireless backhaul in compact deployments. Operating in the 5 GHz spectrum, it delivers up to 1 Gbps aggregate throughput using advanced 2x2 MIMO and 1024 QAM technologies for superior spectrum efficiency. Engineered with AI-driven interference mitigation, the ion4xls intelligently adapts to changing RF environments, ensuring stable, high-capacity connectivity.

Its integrated 18 dBi flat panel antenna, housed in a rugged IP67-rated enclosure, offers reliable performance in both urban and rural deployments. With a sleek, space-saving design and 48V PoE support, the ion4xls simplifies installation while reducing costs. It’s an ideal solution for telecom operators, ISPs, and enterprises seeking scalable, resilient, and cost-effective wireless infrastructure. Whether you are expanding 4G/5G networks, deploying enterprise links, or building rural connectivity, the ion4xls delivers the speed, intelligence, and reliability modern networks demand.

Radio Capabilities

  • 802.11ax

  • 5.1 to 5.9 GHz Frequency Band

  • 2x2 MIMO

  • Upto 1024 QAM Modulation

  • 1 Gbps Peak Data Throughput

  • 20/40/80 MHz Channel Width

  • Upto 27 dBm Tx Power

  • 18 dBi Small form Factor Flat Panel Integrated Antenna

Hardware & Interfaces

  • 1 x 1 GbE

  • IEEE 802.3at, 48V Indoor/Outdoor AC/DC PoE

  • 6 kV Surge Protection

  • IP67 Protection

Wireless

  • Dynamic Channel Selection (DCS)

  • Dynamic Data Rate Selection (DDRS)

  • Automatic Tx Power Control (ATPC)

  • Automatic Channel Selection (ACS)

  • Hitless Channel & Modulation Change

  • Spectrum Analyser

  • Y1731- Bandwidth Notification Message

Networking

  • 4 level Priority QoS

  • IPv4 / IPv6 Support

  • QinQ, Trunk, Access, Transparent and Management VLAN

  • Jumbo Frame up to 9000 Bytes

Security

  • AES-256

  • WPA2/3

  • MAC Based Access Control

Management

  • Web GUI

  • CLI

  • EMS (SNMPv2/v3)

Customizable

  • Dying Gasp

  • GPS

  • Temperature Sensor

  • Extended Temperature
    Note: Variants can be Combined to Meet Unique Deployment Needs

Applications

Telco

Network Scale

Accelerate your network expansion with scalable, high-performance wireless backhaul optimized for 4G and 5G connectivity.

Enterprise

Reliable scalability

Power your business-critical applications with secure, high-speed wireless infrastructure built for reliability and scalability.

ISPs

Faster Deployment

Deliver high-capacity, secure point-to-point connectivity—rapid deployment, exceptional reliability.

Industries

Rugged Use

Reliable, high-throughput connectivity for industrial sites—purpose-built point-to-point links for maximum uptime.

Insights

White Paper

Best Practices for Unlicensed Band Radio (UBR) Installation

Reduce RF Interference and Maximize Wireless Backhaul & Last-Mile Performance...

Case Study

Enhancing Mobile Networks with Efficient Backhaul Solutions

Solving Last-Mile Connectivity Issues Using Advanced UBR Technology...

Video

Experience the Power and Efficiency of HFCL's Advanced Unlicensed Band Radio

Ultra-Fast, Reliable Backhaul with HFCL’s Next-Gen Unlicensed Band Radio...

Frequently Asked Questions

Get answers to key questions about our UBRs, covering use cases,
connectivity, and deployment benefits

How does the ion4xls's small form factor UBR benefit network deployment?

The ion4xls is a 1 Gbps small form factor UBR designed to simplify logistics and deployment. Its compact, lightweight design reduces tower loading and enables you to install high-capacity links in space-constrained locations. The device is engineered to deliver gigabit speeds while its small size helps to reduce infrastructure costs and simplify deployment in challenging terrains like dense urban environments or remote rural areas. This approach can lead to a 50% faster network expansion and significant cost reduction by minimizing the need for expensive fiber laying.

What makes the ion4xls point to point UBR a sustainable and cost-effective choice for network operators?

The ion4xls is an energy-efficient solution that helps reduce operational costs and environmental impact. It is designed to be highly efficient, consuming less than 15W of power while maintaining its high-performance capacity. This energy efficiency, combined with its quick deployment capabilities and reduced infrastructure costs, makes it a valuable alternative to traditional solutions.

How does the ion4xls point to point UBR ensure secure data transmission and network management?

The ion4xls point to point UBR features a comprehensive security suite that includes 256-bit AES encryption and support for WPA, WPA2, and WPA3 for both Personal and Enterprise networks. This ensures secure data transmission and protects against unwanted threats in the wireless communication ecosystem. The device also simplifies operations with intelligent management features like the Two-Way Active Measurement Protocol (TWAMP), which enables real-time performance measurement of links, and Y.1731-BNM, for real-time bandwidth monitoring.

What key features ensure the ion4xls UBR’s durability and reliability in challenging outdoor environments?

The ion4xls is built for extreme durability and is IP67-certified for outdoor ingress protection, allowing it to sustain challenging weather conditions. It can operate in temperatures ranging from -40°C to 55°C (for the extended temperature variant) and is designed to withstand wind loads up to 180 km/hour. The device also includes 4kV surge protection via its PoE port to safeguard against power fluctuations.

How do the intelligent diagnostic and management features of the ion4xls 1 Gbps UBR  simplify network operations?

The ion4xls is equipped with smart features to reduce operational complexity and aid in troubleshooting. The Dying Gasp feature sends a final notification before the device loses power, saving significant time for the operations team. It also includes a GPS-enabled system to assist with network planning and new installations from a central location. An in-built temperature sensor continuously monitors the radio's temperature, allowing for proactive management to prevent potential damage.

What is a point-to-point radio?

A Point-to-Point (P2P) radio creates a dedicated, one-to-one wireless connection between two specific locations, such as two buildings or a central hub and a remote tower. This type of link is often used to extend a network or provide a high-capacity backhaul where running fiber is not feasible. Our P2P UBRs offer fiber-like speeds without the cost or complexity of a physical cable.
