8-Port L2 Industrial Switch

Switching Capacity: 24 Gbps
Forwarding Capacity: 17.86 MPPS

HSP-IO-8GE2S-I2PDH

8-Port PoE+ L2 Managed Industrial Switch with 2x1G SFP and 2x1G RJ45 Uplinks

Overview

Fully Managed L2 Switch with wire speed Non-Blocking Architecture
All Gigabit Ethernet Ports in a fixed configuration
Four 1G PoE+ Capable Access ports
Upto 24 Gbps Switching capacity and up to 12 Gbps of Full-Duplex Throughput
Four 1G Uplink Ports that allow termination of both fiber and copper simultaneously
Dual Redundant Power supply for high availability
Rugged Design with DIN rail mount suitable for outdoor applications
Suitable in an enterprise / telco / campus environments to connect end PoE clients like Wi-Fi AP, CCTV, P2P, P2MP, IoT etc.

8x10/100/1000 Base-T Gigabit Access Ports with PoE+ support
2x10/100/1000 Base-T + 2x1G SFP Gigabit Uplink Ports with the flexibility to terminate the connection on copper as well as fiber simultaneously
One Serial Console Port
Link / Speed / LED Status on all ports
System status LED & onboard RESET button

Support 4094 VLAN IDs, 16K MAC Table, Voice VLAN
L2 Loop Avoidance-STP/RSTP, MSTP, ERPS, STP Root and Edge Port Protection
Multicast - IGMP v1/v2/v3 Snooping, IGMP filtering, IGMP proxy
LACP based LAG and Static LAG with Traffic load share and active standby-policies
Static Routing & Inter-VLAN Routing, Dual Stack and IPv6 Compliant
802.1q and QinQ (Port based and Selective), MVRP
QoS-Up to eight priority queues, Rate Limiting/Policing, CIR/EIR, Shaping (SPQ/WRR/WFQ), Multi-Field (802.1p/DSCP) Classification and Remarking
LLDP/LLDP MED to identify end points, IP Phones etc.
Jumbo MTU upto 9198 Bytes

L2/L3/L4 ACL
802.1X Port Security with Radius CoA, dACL, Accounting & Dynamic VLAN Assignment
TACACS+ / RADIS AAA
DHCP snooping, ARP Inspection
MAC-IP Anti spoofing, MAC Address Notification
Inherent DoS Attack Prevention
Storm Control - Broadcast, Multicast and Unknown Unicast
